Marine Towing Equipment Quick Release Hook Towing Hook A3-A4

Marine Towing Equipment Central Monitor Control Quick Release Hook Towing Hook

Product Introduction:

Quick release mooring hooks systems have been widely used by western port, because of its safety, reliability, feature of
laborsaving and shortcut, etc, since it was used on the port firstly in 1904. In the modernized port building and rebuilding of our country, it has become the trend that quick release mooring hooks systems replace the old bitt.

Quick release mooring hooks systems composed by stranded cable structure and release mooring structure, the main functions below:Reelling the mooring rope automatically. The stranded cable mechine pulls the rope up to the bank automatically. The heavy workused to need two or three people could be finished easily by one people.
Tying up safety and reliability. Under the situation of tying up working, the mechine is in the self-locking state, external force could not pull out the rope from cable hook, safety and reliability of anchoring.

Casting loose quickly. During casting loose, operators turn the control handle to open the locked structure and the anchoring rope will release from hook and cast loose quickly. If emergency such as fire happens on the port or ship, the operator could use the ship leave the parking quickly, so as to guarantee the port or ship safety, avoiding the further extending of loss.

Our company has years' experience on designing and Manufactuer ing of port operating devices, pursuing professional Manufactuer of quick release mooring hooks systems, and absorbing the advanced technique of abroad, together with the reasonable structure and using the advanced processing technical. Strict management makes the products have reliable quality and safe use. Recently, we produce single hook, double hook, triple hook, quadruple-hook, etc. among which the double hook and triple hook are the most widely-ranging used.

Product Parameter

Main Features:
1.Range of movement of hook: tangential movement of medial -lateral 90 degree. Vertical elevation in the range is in 5 degree .
Elevation 0 degree.

2.Operating force of handle<100N
3.The minimun rope strain of release mooring<100N
4.Electrical machine: explosion-proof grade is Diibt4, three phrase current 380V50Hz or 400V60Hz.
5.Magnetic force starter: explosion-proof grade is Diibt4, defend grade IP55, shout-circuit protection and overload protection

Company Profile

Henan Eternalwin Machinery Equipment Co.,Ltd,established in 1998 ,located in crane hometown,which integrates the R&D,manufacture,sales ,installation and service of all kind of overhead crane, gantry crane, hydraulic winch, ship crane, spider crane, vacuum lifting equipment, jib crane, lifting platform. Eternalwin has been “quality first”as a core foundation, which deploys advanced facilities of the domestic and international brand,owns professional R&D term with more than 600 people.The team is the largest R&D term in China’s general crane industry, and has won over 80 national provincial man municipal scientific achievements, which lays a solid foundation for producing high quality products. Eternalwin adheres to “ customer-oriented” marketing concept, owns strong sales term and after service power, who always is ready to provides quality service to our customers. Eternalwin insists on the principle of “delicate manufacture,continual improvement,seeking superiority,satisfying customer”and by absorbing management essence home and abroad,introducing first-class talents,implementing first-class management and manufacturing first-class products. Sincerely cooperating with all the peoples from all walks of lift to realize mutual benefit.

Packing and Shipping

FAQ

1. What after-sale service do you provide?
We have professional sales team and technical team for all customer. We can serve 24 hours a day for you.
2. What payment methods do you support?
We have many kinds of payment for your reference ,such as Western Union, Paypal, L/C, T/T and so on.
3. How to delivery the goods?
We often shipment goods by sea,which is cheaper than by air. It depends on your specific requirement.
4. What is your warranty service about machine?
Our machine has one year warranty time, and our engineering team available for oversea service with crane installation, inspection and commissioning.
5. What is your trade terms?
We have EXW, FOB, CIF, CFR for you to choose, and we can change according to your requirements.
6.Why should I choose your products?
We can provide high quality and low price products for you.
